LC40 Series
T-slot extrusion compatible linear guides, motor-ready
Series Specifications
| Maximum Moment (Roll) | 6 N⋅m (4.4 ft⋅lb) |
| Maximum Moment (Pitch) | 7 N⋅m (5.2 ft⋅lb) |
| Maximum Moment (Yaw) | 7 N⋅m (5.2 ft⋅lb) |
| Guide Type | Recirculating Ball Linear Guide |
| Axes of Motion | 1 |
| Operating Temperature Range | 0 to 50 °C |
| CE Compliant |  |
| Vacuum Compatible |  |
Part Specifications Comparison
Showing 276 of 276 Parts.
| Part Number | Travel Range | Maximum Centered Load | Stiffness in Pitch | Stiffness in Roll | Stiffness in Yaw | Linear Motion Per Motor Rev | Mechanical Drive System | Weight |
|---|---|---|---|---|---|---|---|---|
| LC40B0100 | 100 mm (3.937") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 1.461 kg (3.221 lb) |
| LC40B0100-N2 | 30 mm (1.181") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 1.656 kg (3.651 lb) | |||
| LC40G0100 | 100 mm (3.937") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 0.672 kg (1.482 lb) | ||
| LC40G0100-N2 | 30 mm (1.181") | 1000 N (224.3 lb) | 0.867 kg (1.911 lb) | |||||
| LC40B0150 | 150 mm (5.905") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 1.581 kg (3.486 lb) |
| LC40B0150-N2 | 80 mm (3.150") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 1.776 kg (3.915 lb) | |||
| LC40G0150 | 150 mm (5.905") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 0.789 kg (1.739 lb) | ||
| LC40G0150-N2 | 80 mm (3.150") | 1000 N (224.3 lb) | 0.984 kg (2.169 lb) | |||||
| LC40B0200 | 200 mm (7.874") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 1.701 kg (3.750 lb) |
| LC40B0200-N2 | 130 mm (5.118") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 1.896 kg (4.180 lb) | |||
| LC40G0200 | 200 mm (7.874") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 0.907 kg (2.000 lb) | ||
| LC40G0200-N2 | 130 mm (5.118") | 1000 N (224.3 lb) | 1.102 kg (2.429 lb) | |||||
| LC40B0250 | 250 mm (9.843") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 1.821 kg (4.015 lb) |
| LC40B0250-N2 | 180 mm (7.087") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 2.016 kg (4.445 lb) | |||
| LC40G0250 | 250 mm (9.843") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 1.025 kg (2.260 lb) | ||
| LC40G0250-N2 | 180 mm (7.087") | 1000 N (224.3 lb) | 1.22 kg (2.690 lb) | |||||
| LC40B0300 | 300 mm (11.811") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 1.942 kg (4.281 lb) |
| LC40B0300-N2 | 230 mm (9.055") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 2.137 kg (4.711 lb) | |||
| LC40G0300 | 300 mm (11.811") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 1.143 kg (2.520 lb) | ||
| LC40G0300-N2 | 230 mm (9.055") | 1000 N (224.3 lb) | 1.338 kg (2.950 lb) | |||||
| LC40B0350 | 350 mm (13.780") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 2.062 kg (4.546 lb) |
| LC40B0350-N2 | 280 mm (11.024") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 2.257 kg (4.976 lb) | |||
| LC40G0350 | 350 mm (13.780") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 1.26 kg (2.778 lb) | ||
| LC40G0350-N2 | 280 mm (11.024") | 1000 N (224.3 lb) | 1.455 kg (3.208 lb) | |||||
| LC40B0400 | 400 mm (15.748") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 2.182 kg (4.810 lb) |
| LC40B0400-N2 | 330 mm (12.992") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 2.377 kg (5.240 lb) | |||
| LC40G0400 | 400 mm (15.748") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 1.378 kg (3.038 lb) | ||
| LC40G0400-N2 | 330 mm (12.992") | 1000 N (224.3 lb) | 1.573 kg (3.468 lb) | |||||
| LC40B0450 | 450 mm (17.716") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 2.302 kg (5.075 lb) |
| LC40B0450-N2 | 380 mm (14.961") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 2.497 kg (5.505 lb) | |||
| LC40G0450 | 450 mm (17.716") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 1.496 kg (3.298 lb) | ||
| LC40G0450-N2 | 380 mm (14.961") | 1000 N (224.3 lb) | 1.691 kg (3.728 lb) | |||||
| LC40B0500 | 500 mm (19.685") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 2.423 kg (5.342 lb) |
| LC40B0500-N2 | 430 mm (16.929") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 2.618 kg (5.772 lb) | |||
| LC40G0500 | 500 mm (19.685") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 1.614 kg (3.558 lb) | ||
| LC40G0500-N2 | 430 mm (16.929") | 1000 N (224.3 lb) | 1.809 kg (3.988 lb) | |||||
| LC40B0550 | 550 mm (21.654") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 2.543 kg (5.606 lb) |
| LC40B0550-N2 | 480 mm (18.898") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 2.738 kg (6.036 lb) | |||
| LC40G0550 | 550 mm (21.654") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 1.731 kg (3.816 lb) | ||
| LC40G0550-N2 | 480 mm (18.898") | 1000 N (224.3 lb) | 1.926 kg (4.246 lb) | |||||
| LC40B0600 | 600 mm (23.622") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 2.663 kg (5.871 lb) |
| LC40B0600-N2 | 530 mm (20.866") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 2.858 kg (6.301 lb) | |||
| LC40G0600 | 600 mm (23.622") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 1.849 kg (4.076 lb) | ||
| LC40G0600-N2 | 530 mm (20.866") | 1000 N (224.3 lb) | 2.044 kg (4.506 lb) | |||||
| LC40B0650 | 650 mm (25.591") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 2.783 kg (6.135 lb) |
| LC40B0650-N2 | 580 mm (22.835") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 2.978 kg (6.565 lb) | |||
| LC40G0650 | 650 mm (25.591") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 1.967 kg (4.336 lb) | ||
| LC40G0650-N2 | 580 mm (22.835") | 1000 N (224.3 lb) | 2.162 kg (4.766 lb) | |||||
| LC40B0700 | 700 mm (27.559") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 2.904 kg (6.402 lb) |
| LC40B0700-N2 | 630 mm (24.803") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 3.099 kg (6.832 lb) | |||
| LC40G0700 | 700 mm (27.559") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 2.085 kg (4.597 lb) | ||
| LC40G0700-N2 | 630 mm (24.803") | 1000 N (224.3 lb) | 2.28 kg (5.027 lb) | |||||
| LC40B0750 | 750 mm (29.528") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 3.024 kg (6.667 lb) |
| LC40B0750-N2 | 680 mm (26.772") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 3.219 kg (7.097 lb) | |||
| LC40G0750 | 750 mm (29.528") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 2.202 kg (4.855 lb) | ||
| LC40G0750-N2 | 680 mm (26.772") | 1000 N (224.3 lb) | 2.397 kg (5.284 lb) | |||||
| LC40B0800 | 800 mm (31.496") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 3.144 kg (6.931 lb) |
| LC40B0800-N2 | 730 mm (28.740") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 3.339 kg (7.361 lb) | |||
| LC40G0800 | 800 mm (31.496") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 2.32 kg (5.115 lb) | ||
| LC40G0800-N2 | 730 mm (28.740") | 1000 N (224.3 lb) | 2.515 kg (5.545 lb) | |||||
| LC40B0850 | 850 mm (33.465") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 3.264 kg (7.196 lb) |
| LC40B0850-N2 | 780 mm (30.709") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 3.459 kg (7.626 lb) | |||
| LC40G0850 | 850 mm (33.465") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 2.438 kg (5.375 lb) | ||
| LC40G0850-N2 | 780 mm (30.709") | 1000 N (224.3 lb) | 2.633 kg (5.805 lb) | |||||
| LC40B0900 | 900 mm (35.433") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 3.385 kg (7.463 lb) |
| LC40B0900-N2 | 830 mm (32.677") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 3.58 kg (7.893 lb) | |||
| LC40G0900 | 900 mm (35.433") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 2.556 kg (5.635 lb) | ||
| LC40G0900-N2 | 830 mm (32.677") | 1000 N (224.3 lb) | 2.751 kg (6.065 lb) | |||||
| LC40B0950 | 950 mm (37.401") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 3.505 kg (7.727 lb) |
| LC40B0950-N2 | 880 mm (34.646") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 3.7 kg (8.157 lb) | |||
| LC40G0950 | 950 mm (37.401") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 2.673 kg (5.893 lb) | ||
| LC40G0950-N2 | 880 mm (34.646") | 1000 N (224.3 lb) | 2.868 kg (6.323 lb) | |||||
| LC40B1000 | 1000 mm (39.370") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 3.625 kg (7.992 lb) |
| LC40B1000-N2 | 930 mm (36.614") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 3.82 kg (8.422 lb) | |||
| LC40G1000 | 1000 mm (39.370") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 2.791 kg (6.153 lb) | ||
| LC40G1000-N2 | 930 mm (36.614") | 1000 N (224.3 lb) | 2.986 kg (6.583 lb) | |||||
| LC40B1050 | 1050 mm (41.339") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 3.745 kg (8.256 lb) |
| LC40B1050-N2 | 980 mm (38.583") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 3.94 kg (8.686 lb) | |||
| LC40G1050 | 1050 mm (41.339") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 2.909 kg (6.413 lb) | ||
| LC40G1050-N2 | 980 mm (38.583") | 1000 N (224.3 lb) | 3.104 kg (6.843 lb) | |||||
| LC40B1100 | 1100 mm (43.307") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 3.866 kg (8.523 lb) |
| LC40B1100-N2 | 1030 mm (40.551") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 4.061 kg (8.953 lb) | |||
| LC40G1100 | 1100 mm (43.307") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 3.027 kg (6.673 lb) | ||
| LC40G1100-N2 | 1030 mm (40.551") | 1000 N (224.3 lb) | 3.222 kg (7.103 lb) | |||||
| LC40B1150 | 1150 mm (45.276") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 3.986 kg (8.788 lb) |
| LC40B1150-N2 | 1080 mm (42.520") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 4.181 kg (9.218 lb) | |||
| LC40G1150 | 1150 mm (45.276") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 3.144 kg (6.931 lb) | ||
| LC40G1150-N2 | 1080 mm (42.520") | 1000 N (224.3 lb) | 3.339 kg (7.361 lb) | |||||
| LC40B1200 | 1200 mm (47.244") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 4.106 kg (9.052 lb) |
| LC40B1200-N2 | 1130 mm (44.488") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 4.301 kg (9.482 lb) | |||
| LC40G1200 | 1200 mm (47.244") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 3.262 kg (7.191 lb) | ||
| LC40G1200-N2 | 1130 mm (44.488") | 1000 N (224.3 lb) | 3.457 kg (7.621 lb) | |||||
| LC40B1250 | 1250 mm (49.213") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 4.226 kg (9.317 lb) |
| LC40B1250-N2 | 1180 mm (46.457") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 4.421 kg (9.747 lb) | |||
| LC40G1250 | 1250 mm (49.213") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 3.38 kg (7.452 lb) | ||
| LC40G1250-N2 | 1180 mm (46.457") | 1000 N (224.3 lb) | 3.575 kg (7.882 lb) | |||||
| LC40B1300 | 1300 mm (51.181") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 4.347 kg (9.583 lb) |
| LC40B1300-N2 | 1230 mm (48.425") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 4.542 kg (10.013 lb) | |||
| LC40G1300 | 1300 mm (51.181") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 3.498 kg (7.712 lb) | ||
| LC40G1300-N2 | 1230 mm (48.425") | 1000 N (224.3 lb) | 3.693 kg (8.142 lb) | |||||
| LC40B1350 | 1350 mm (53.150") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 4.467 kg (9.848 lb) |
| LC40B1350-N2 | 1280 mm (50.394") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 4.662 kg (10.278 lb) | |||
| LC40G1350 | 1350 mm (53.150") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 3.615 kg (7.970 lb) | ||
| LC40G1350-N2 | 1280 mm (50.394") | 1000 N (224.3 lb) | 3.81 kg (8.400 lb) | |||||
| LC40B1400 | 1400 mm (55.118") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 4.587 kg (10.113 lb) |
| LC40B1400-N2 | 1330 mm (52.362") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 4.782 kg (10.542 lb) | |||
| LC40G1400 | 1400 mm (55.118") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 3.733 kg (8.230 lb) | ||
| LC40G1400-N2 | 1330 mm (52.362") | 1000 N (224.3 lb) | 3.928 kg (8.660 lb) | |||||
| LC40B1450 | 1450 mm (57.087") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 4.707 kg (10.377 lb) |
| LC40B1450-N2 | 1380 mm (54.331") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 4.902 kg (10.807 lb) | |||
| LC40G1450 | 1450 mm (57.087") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 3.851 kg (8.490 lb) | ||
| LC40G1450-N2 | 1380 mm (54.331") | 1000 N (224.3 lb) | 4.046 kg (8.920 lb) | |||||
| LC40B1500 | 1500 mm (59.055") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 4.828 kg (10.644 lb) |
| LC40B1500-N2 | 1430 mm (56.299") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 5.023 kg (11.074 lb) | |||
| LC40G1500 | 1500 mm (59.055") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 3.969 kg (8.750 lb) | ||
| LC40G1500-N2 | 1430 mm (56.299") | 1000 N (224.3 lb) | 4.164 kg (9.180 lb) | |||||
| LC40B1550 | 1550 mm (61.024") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 4.948 kg (10.908 lb) |
| LC40B1550-N2 | 1480 mm (58.268") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 5.143 kg (11.338 lb) | |||
| LC40G1550 | 1550 mm (61.024") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 4.086 kg (9.008 lb) | ||
| LC40G1550-N2 | 1480 mm (58.268") | 1000 N (224.3 lb) | 4.281 kg (9.438 lb) | |||||
| LC40B1600 | 1600 mm (62.992") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 5.068 kg (11.173 lb) |
| LC40B1600-N2 | 1530 mm (60.236") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 5.263 kg (11.603 lb) | |||
| LC40G1600 | 1600 mm (62.992") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 4.204 kg (9.268 lb) | ||
| LC40G1600-N2 | 1530 mm (60.236") | 1000 N (224.3 lb) | 4.399 kg (9.698 lb) | |||||
| LC40B1650 | 1650 mm (64.961") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 5.188 kg (11.438 lb) |
| LC40B1650-N2 | 1580 mm (62.205") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 5.383 kg (11.867 lb) | |||
| LC40G1650 | 1650 mm (64.961") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 4.322 kg (9.528 lb) | ||
| LC40G1650-N2 | 1580 mm (62.205") | 1000 N (224.3 lb) | 4.517 kg (9.958 lb) | |||||
| LC40B1700 | 1700 mm (66.929") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 5.309 kg (11.704 lb) |
| LC40B1700-N2 | 1630 mm (64.173") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 5.504 kg (12.134 lb) | |||
| LC40G1700 | 1700 mm (66.929") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 4.44 kg (9.789 lb) | ||
| LC40G1700-N2 | 1630 mm (64.173") | 1000 N (224.3 lb) | 4.635 kg (10.218 lb) | |||||
| LC40B1750 | 1750 mm (68.898") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 5.429 kg (11.969 lb) |
| LC40B1750-N2 | 1680 mm (66.142") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 5.624 kg (12.399 lb) | |||
| LC40G1750 | 1750 mm (68.898") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 4.557 kg (10.046 lb) | ||
| LC40G1750-N2 | 1680 mm (66.142") | 1000 N (224.3 lb) | 4.752 kg (10.476 lb) | |||||
| LC40B1800 | 1800 mm (70.866") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 5.549 kg (12.233 lb) |
| LC40B1800-N2 | 1730 mm (68.110") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 5.744 kg (12.663 lb) | |||
| LC40G1800 | 1800 mm (70.866") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 4.675 kg (10.307 lb) | ||
| LC40G1800-N2 | 1730 mm (68.110") | 1000 N (224.3 lb) | 4.87 kg (10.736 lb) | |||||
| LC40B1850 | 1850 mm (72.835") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 5.669 kg (12.498 lb) |
| LC40B1850-N2 | 1780 mm (70.079") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 5.864 kg (12.928 lb) | |||
| LC40G1850 | 1850 mm (72.835") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 4.793 kg (10.567 lb) | ||
| LC40G1850-N2 | 1780 mm (70.079") | 1000 N (224.3 lb) | 4.988 kg (10.997 lb) | |||||
| LC40B1900 | 1900 mm (74.803") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 5.79 kg (12.765 lb) |
| LC40B1900-N2 | 1830 mm (72.047") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 5.985 kg (13.195 lb) | |||
| LC40G1900 | 1900 mm (74.803") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 4.911 kg (10.827 lb) | ||
| LC40G1900-N2 | 1830 mm (72.047") | 1000 N (224.3 lb) | 5.106 kg (11.257 lb) | |||||
| LC40B1950 | 1950 mm (76.772") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 5.91 kg (13.029 lb) |
| LC40B1950-N2 | 1880 mm (74.016") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 6.105 kg (13.459 lb) | |||
| LC40G1950 | 1950 mm (76.772") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 5.028 kg (11.085 lb) | ||
| LC40G1950-N2 | 1880 mm (74.016") | 1000 N (224.3 lb) | 5.223 kg (11.515 lb) | |||||
| LC40B2000 | 2000 mm (78.740") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 6.03 kg (13.294 lb) |
| LC40B2000-N2 | 1930 mm (75.984") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 6.225 kg (13.724 lb) | |||
| LC40G2000 | 2000 mm (78.740") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 5.146 kg (11.345 lb) | ||
| LC40G2000-N2 | 1930 mm (75.984") | 1000 N (224.3 lb) | 5.341 kg (11.775 lb) | |||||
| LC40B2050 | 2050 mm (80.709") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 6.15 kg (13.558 lb) |
| LC40B2050-N2 | 1980 mm (77.953") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 6.345 kg (13.988 lb) | |||
| LC40G2050 | 2050 mm (80.709") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 5.264 kg (11.605 lb) | ||
| LC40G2050-N2 | 1980 mm (77.953") | 1000 N (224.3 lb) | 5.459 kg (12.035 lb) | |||||
| LC40B2100 | 2100 mm (82.677") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 6.271 kg (13.825 lb) |
| LC40B2100-N2 | 2030 mm (79.921") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 6.466 kg (14.255 lb) | |||
| LC40G2100 | 2100 mm (82.677") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 5.382 kg (11.865 lb) | ||
| LC40G2100-N2 | 2030 mm (79.921") | 1000 N (224.3 lb) | 5.577 kg (12.295 lb) | |||||
| LC40B2150 | 2150 mm (84.645") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 6.391 kg (14.090 lb) |
| LC40B2150-N2 | 2080 mm (81.890") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 6.586 kg (14.520 lb) | |||
| LC40G2150 | 2150 mm (84.645") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 5.499 kg (12.123 lb) | ||
| LC40G2150-N2 | 2080 mm (81.890") | 1000 N (224.3 lb) | 5.694 kg (12.553 lb) | |||||
| LC40B2200 | 2200 mm (86.614") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 6.511 kg (14.354 lb) |
| LC40B2200-N2 | 2130 mm (83.858") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 6.706 kg (14.784 lb) | |||
| LC40G2200 | 2200 mm (86.614") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 5.617 kg (12.383 lb) | ||
| LC40G2200-N2 | 2130 mm (83.858") | 1000 N (224.3 lb) | 5.812 kg (12.813 lb) | |||||
| LC40B2250 | 2250 mm (88.583") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 6.631 kg (14.619 lb) |
| LC40B2250-N2 | 2180 mm (85.827") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 6.826 kg (15.049 lb) | |||
| LC40G2250 | 2250 mm (88.583") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 5.735 kg (12.643 lb) | ||
| LC40G2250-N2 | 2180 mm (85.827") | 1000 N (224.3 lb) | 5.93 kg (13.073 lb) | |||||
| LC40B2300 | 2300 mm (90.551") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 6.752 kg (14.886 lb) |
| LC40B2300-N2 | 2230 mm (87.795") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 6.947 kg (15.315 lb) | |||
| LC40G2300 | 2300 mm (90.551") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 5.853 kg (12.904 lb) | ||
| LC40G2300-N2 | 2230 mm (87.795") | 1000 N (224.3 lb) | 6.048 kg (13.334 lb) | |||||
| LC40B2350 | 2350 mm (92.520") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 6.872 kg (15.150 lb) |
| LC40B2350-N2 | 2280 mm (89.764") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 7.067 kg (15.580 lb) | |||
| LC40G2350 | 2350 mm (92.520") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 5.97 kg (13.162 lb) | ||
| LC40G2350-N2 | 2280 mm (89.764") | 1000 N (224.3 lb) | 6.165 kg (13.591 lb) | |||||
| LC40B2400 | 2400 mm (94.488") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 6.992 kg (15.415 lb) |
| LC40B2400-N2 | 2330 mm (91.732") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 7.187 kg (15.845 lb) | |||
| LC40G2400 | 2400 mm (94.488") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 6.088 kg (13.422 lb) | ||
| LC40G2400-N2 | 2330 mm (91.732") | 1000 N (224.3 lb) | 6.283 kg (13.852 lb) | |||||
| LC40B2450 | 2450 mm (96.457") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 7.112 kg (15.679 lb) |
| LC40B2450-N2 | 2380 mm (93.701") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 7.307 kg (16.109 lb) | |||
| LC40G2450 | 2450 mm (96.457") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 6.206 kg (13.682 lb) | ||
| LC40G2450-N2 | 2380 mm (93.701") | 1000 N (224.3 lb) | 6.401 kg (14.112 lb) | |||||
| LC40B2500 | 2500 mm (98.425") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 7.233 kg (15.946 lb) |
| LC40B2500-N2 | 2430 mm (95.669") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 7.428 kg (16.376 lb) | |||
| LC40G2500 | 2500 mm (98.425") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 6.324 kg (13.942 lb) | ||
| LC40G2500-N2 | 2430 mm (95.669") | 1000 N (224.3 lb) | 6.519 kg (14.372 lb) | |||||
| LC40B2550 | 2550 mm (100.394") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 7.353 kg (16.211 lb) |
| LC40B2550-N2 | 2480 mm (97.638") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 7.548 kg (16.640 lb) | |||
| LC40G2550 | 2550 mm (100.394") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 6.441 kg (14.200 lb) | ||
| LC40G2550-N2 | 2480 mm (97.638") | 1000 N (224.3 lb) | 6.636 kg (14.630 lb) | |||||
| LC40B2600 | 2600 mm (102.362") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 7.473 kg (16.475 lb) |
| LC40B2600-N2 | 2530 mm (99.606") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 7.668 kg (16.905 lb) | |||
| LC40G2600 | 2600 mm (102.362") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 6.559 kg (14.460 lb) | ||
| LC40G2600-N2 | 2530 mm (99.606") | 1000 N (224.3 lb) | 6.754 kg (14.890 lb) | |||||
| LC40B2650 | 2650 mm (104.331") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 7.593 kg (16.740 lb) |
| LC40B2650-N2 | 2580 mm (101.575") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 7.788 kg (17.170 lb) | |||
| LC40G2650 | 2650 mm (104.331") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 6.677 kg (14.720 lb) | ||
| LC40G2650-N2 | 2580 mm (101.575") | 1000 N (224.3 lb) | 6.872 kg (15.150 lb) | |||||
| LC40B2700 | 2700 mm (106.299") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 7.714 kg (17.006 lb) |
| LC40B2700-N2 | 2630 mm (103.543") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 7.909 kg (17.436 lb) | |||
| LC40G2700 | 2700 mm (106.299") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 6.795 kg (14.980 lb) | ||
| LC40G2700-N2 | 2630 mm (103.543") | 1000 N (224.3 lb) | 6.99 kg (15.410 lb) | |||||
| LC40B2750 | 2750 mm (108.268") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 7.834 kg (17.271 lb) |
| LC40B2750-N2 | 2680 mm (105.512") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 8.029 kg (17.701 lb) | |||
| LC40G2750 | 2750 mm (108.268") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 6.912 kg (15.238 lb) | ||
| LC40G2750-N2 | 2680 mm (105.512") | 1000 N (224.3 lb) | 7.107 kg (15.668 lb) | |||||
| LC40B2800 | 2800 mm (110.236") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 7.954 kg (17.536 lb) |
| LC40B2800-N2 | 2730 mm (107.480") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 8.149 kg (17.965 lb) | |||
| LC40G2800 | 2800 mm (110.236") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 7.03 kg (15.498 lb) | ||
| LC40G2800-N2 | 2730 mm (107.480") | 1000 N (224.3 lb) | 7.225 kg (15.928 lb) | |||||
| LC40B2850 | 2850 mm (112.205") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 8.074 kg (17.800 lb) |
| LC40B2850-N2 | 2780 mm (109.449") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 8.269 kg (18.230 lb) | |||
| LC40G2850 | 2850 mm (112.205") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 7.148 kg (15.759 lb) | ||
| LC40G2850-N2 | 2780 mm (109.449") | 1000 N (224.3 lb) | 7.343 kg (16.189 lb) | |||||
| LC40B2900 | 2900 mm (114.173") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 8.195 kg (18.067 lb) |
| LC40B2900-N2 | 2830 mm (111.417") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 8.39 kg (18.497 lb) | |||
| LC40G2900 | 2900 mm (114.173") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 7.266 kg (16.019 lb) | ||
| LC40G2900-N2 | 2830 mm (111.417") | 1000 N (224.3 lb) | 7.461 kg (16.449 lb) | |||||
| LC40B2950 | 2950 mm (116.142") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 8.315 kg (18.331 lb) |
| LC40B2950-N2 | 2880 mm (113.386") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 8.51 kg (18.761 lb) | |||
| LC40G2950 | 2950 mm (116.142") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 7.383 kg (16.277 lb) | ||
| LC40G2950-N2 | 2880 mm (113.386") | 1000 N (224.3 lb) | 7.578 kg (16.707 lb) | |||||
| LC40B3000 | 3000 mm (118.110") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 8.435 kg (18.596 lb) |
| LC40B3000-N2 | 2930 mm (115.354") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 8.63 kg (19.026 lb) | |||
| LC40G3000 | 3000 mm (118.110") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 7.501 kg (16.537 lb) | ||
| LC40G3000-N2 | 2930 mm (115.354") | 1000 N (224.3 lb) | 7.696 kg (16.967 lb) | |||||
| LC40B3050 | 3050 mm (120.079") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 8.555 kg (18.861 lb) |
| LC40B3050-N2 | 2980 mm (117.323") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 8.75 kg (19.290 lb) | |||
| LC40G3050 | 3050 mm (120.079") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 7.619 kg (16.797 lb) | ||
| LC40G3050-N2 | 2980 mm (117.323") | 1000 N (224.3 lb) | 7.814 kg (17.227 lb) | |||||
| LC40B3100 | 3100 mm (122.047") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 8.676 kg (19.127 lb) |
| LC40B3100-N2 | 3030 mm (119.291") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 8.871 kg (19.557 lb) | |||
| LC40G3100 | 3100 mm (122.047") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 7.737 kg (17.057 lb) | ||
| LC40G3100-N2 | 3030 mm (119.291") | 1000 N (224.3 lb) | 7.932 kg (17.487 lb) | |||||
| LC40B3150 | 3150 mm (124.016") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 8.796 kg (19.392 lb) |
| LC40B3150-N2 | 3080 mm (121.260") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 8.991 kg (19.822 lb) | |||
| LC40G3150 | 3150 mm (124.016") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 7.854 kg (17.315 lb) | ||
| LC40G3150-N2 | 3080 mm (121.260") | 1000 N (224.3 lb) | 8.049 kg (17.745 lb) | |||||
| LC40B3200 | 3200 mm (125.984") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 8.916 kg (19.656 lb) |
| LC40B3200-N2 | 3130 mm (123.228") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 9.111 kg (20.086 lb) | |||
| LC40G3200 | 3200 mm (125.984") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 7.972 kg (17.575 lb) | ||
| LC40G3200-N2 | 3130 mm (123.228") | 1000 N (224.3 lb) | 8.167 kg (18.005 lb) | |||||
| LC40B3250 | 3250 mm (127.953") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 9.036 kg (19.921 lb) |
| LC40B3250-N2 | 3180 mm (125.197") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 9.231 kg (20.351 lb) | |||
| LC40G3250 | 3250 mm (127.953") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 8.09 kg (17.835 lb) | ||
| LC40G3250-N2 | 3180 mm (125.197") | 1000 N (224.3 lb) | 8.285 kg (18.265 lb) | |||||
| LC40B3300 | 3300 mm (129.921") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 9.157 kg (20.188 lb) |
| LC40B3300-N2 | 3230 mm (127.165") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 9.352 kg (20.618 lb) | |||
| LC40G3300 | 3300 mm (129.921") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 8.208 kg (18.096 lb) | ||
| LC40G3300-N2 | 3230 mm (127.165") | 1000 N (224.3 lb) | 8.403 kg (18.525 lb) | |||||
| LC40B3350 | 3350 mm (131.889") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 9.277 kg (20.452 lb) |
| LC40B3350-N2 | 3280 mm (129.134") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 9.472 kg (20.882 lb) | |||
| LC40G3350 | 3350 mm (131.889") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 8.325 kg (18.353 lb) | ||
| LC40G3350-N2 | 3280 mm (129.134") | 1000 N (224.3 lb) | 8.52 kg (18.783 lb) | |||||
| LC40B3400 | 3400 mm (133.858") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 9.397 kg (20.717 lb) |
| LC40B3400-N2 | 3330 mm (131.102") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 9.592 kg (21.147 lb) | |||
| LC40G3400 | 3400 mm (133.858") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 8.443 kg (18.614 lb) | ||
| LC40G3400-N2 | 3330 mm (131.102") | 1000 N (224.3 lb) | 8.638 kg (19.044 lb) | |||||
| LC40B3450 | 3450 mm (135.827") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 9.517 kg (20.981 lb) |
| LC40B3450-N2 | 3380 mm (133.071") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 9.712 kg (21.411 lb) | |||
| LC40G3450 | 3450 mm (135.827") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 8.561 kg (18.874 lb) | ||
| LC40G3450-N2 | 3380 mm (133.071") | 1000 N (224.3 lb) | 8.756 kg (19.304 lb) | |||||
| LC40B3500 | 3500 mm (137.795") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 90 mm (3.543") | Synchronous belt | 9.638 kg (21.248 lb) |
| LC40B3500-N2 | 3430 mm (135.039") | 1000 N (224.3 lb) | 90 mm (3.543") | Synchronous belt | 9.833 kg (21.678 lb) | |||
| LC40G3500 | 3500 mm (137.795") | 500 N (112.1 lb) | 180 N⋅m/° (97 µrad/N⋅m) | 24 N⋅m/° (727 µrad/N⋅m) | 180 N⋅m/° (97 µrad/N⋅m) | 8.679 kg (19.134 lb) | ||
| LC40G3500-N2 | 3430 mm (135.039") | 1000 N (224.3 lb) | 8.874 kg (19.564 lb) |
Specification Charts & Notes
Thrust or torque is a function of speed. The values given above are maximums. These values cannot both be achieved simultaneously (i.e. at maximum speed, the unit will not produce maximum thrust).
