Representative Image
GSM Family
Goniometers
- 40 mm and 60 mm centre of rotation options allow for two axes of motion about a common centre of rotation
- Crossed roller bearings for smooth motion and high stiffness
- Vacuum rated versions available
- Built-in controller or motor-only models
- Motor encoder option for slip/stall detection and automatic recovery
- Contact us for information and custom options for cleanroom use
| Range | Best Accuracy | Best Backlash | Highest Speed | Load |
|---|---|---|---|---|
+/- 10° | 0.06° (1.047 mrad) | < 0.01° (< 0.174 mrad) | 30°/s (5 rpm) | 30 N (6.7 lb) |
Have a Question?
| Series Name | Built-In Controller | Built-In Encoder | Built-In Motor | Vacuum Rating | Price Range (USD) * | Current Lead Times | Add To Compare |
|---|---|---|---|---|---|---|---|
| GSM | Not available | Not available | Stepper | Available | $2,049 | 4–7 days | |
| GSM-E | Not available | Motor/rotary | Stepper | Available | $2,280 | 4–7 days | |
| X-GSM | Available | Not available | Stepper | Available | $2,741 – $2,909 | 4–7 days | |
| X-GSM-E | Available | Motor/rotary | Stepper | Available | $3,002 – $3,170 | 4–7 days | |
| X-GSM-SV2 | Available | Not available | Stepper | High (10-6 torr) | $6,041 | 7–10 days | |
| GSM-V2 | Not available | Not available | Stepper | High (10-6 torr) | $4,825 | 7–10 days | |
| X-GSM-SV1 | Available | Not available | Stepper | Low (10-3 torr) | $5,289 | 4–7 days | |
| GSM-V1 | Not available | Not available | Stepper | Low (10-3 torr) | $4,279 | 4–7 days |
* These are our direct prices in USD to customers in North America. If you are in Canada, click the Canadian flag icon at the top right of the page to see CAD prices. If you are in a country outside North America where we have an exclusive distributor, please check with the distributor for pricing. Distributor prices might be slightly higher to factor in shipping and import fees. Click here for a list of Zaber's Distributors.
Customization
Whether you need modifications to standard products or have unique stage or system needs, our Product Customization Team is dedicated to building tailored solutions.
Response Time Promise: 1 Business Day
