OME-TIFF Metadata Generation for Image Acquisition

The Open Microscopy Environment (OME) data model was developed to structure experiment data for biological microscopy imaging. The model can be expressed as just metadata in OME-XML files or embedded with image data in OME-TIFF files.

This example demonstrates how to combine an .ome.xml file with image data to create an .ome.tiff file. OME-TIFF organises frames along TCZYX axes (Time, Channel, Z, Y, X) allowing multi-dimensional acquisitions to be stored in a single file alongside structured metadata. The generated OME-TIFF files can be opened directly in bioimaging tools or libraries and can be further processed for image analysis, stitching, or other workflows.

The example was specifically developed to be used with the Zaber Launcher Microscopy app that exports image metadata as OME-XML files after image acquisition.

Hardware Requirements

This example does not require any hardware to run. The example assumes that an image acquisition has been completed using a Zaber microscope.

Dependencies / Software Requirements / Prerequisites

This example uses uv to manage the virtual environment and dependencies. The dependencies are listed in pyproject.toml.

This example requires an image acquisition to be completed prior to running, preferably with Zaber Launcher Microscope App, and requires the following to run:

• OME XML metadata: Exported using the Zaber Launcher Microscope App
• Image Acquisition Directory: Contains acquisition images captured using third party imaging software. The example assumes all images have the same dimensions.

Running the Script

• -m, --ome-metadata: Path to the .ome.xml metadata file.
• -d, --acquisition-dir: Directory containing acquisition images.
• -o, --output-directory (Optional): Output directory for generated .ome.tiff file.

To run the example:

cd examples/microscope_ome_tiff_generation/
uv run ome_tiff.py -m ./sample_data/xy.ome.xml -d ./sample_data -o ./output

Customising Example

The OMETiffWriter class provided in the example can be modified to suit your specific use case. The example can be easily modified to extend supported image formats or add/customise metadata for the generated .ome.tiff file.

Acquisition image Format / File Structure

OMETiffWriter assumes that images in the acquisition directory are named corresponding to the acquisition order for e.g image001.png, image002.png etc. If your files are sorted in a different way, you can override or modify the get_acquisition_order function to match your setup.

The example only looks for image file names matching the patterns in the IMAGE_FORMAT_PATTERNS. Modify this constant to filter or extend image files discovered.

Modifying Metadata

OMETiffWriter uses the ome_types library to parse metadata XML into a python object which is further modified in modify_metadata.

The code in modify_metadata looks at the image data to derive the pixel_type, interleaved and samples_per_pixel attributes for OME Image and Pixels objects. These are often required by OME-TIFF readers for rendering.

Additional logic to modify metadata can be added to this method.

    def modify_metadata(self, sample: np.ndarray) -> str:
        # get OME metadata object
        ome = from_xml(self.metadata)
        pixel_type = self.DTYPE_TO_OME.get(sample.dtype)
        if sample.ndim == self.NUM_CHANNELS_GREYSCALE:
            # derive metadata from image shape
        else:
            # ...
        for image in ome.images:
            # add derived metadata to metadata object
        # your metadata logic here
        return ome.to_xml()

Notes

TiffWriter

This example uses the tifffile library to write the OME-TIFF file.

Even though OME-TIFF can support multi-file datasets or partial datasets, this example writes a single complete TIFF file. As specified in the OME TIFF documentation, the actual image data is stored in Tiff Image File Directories (IFDs, sometimes used interchangeably with pages). The ImageDescription of the first IFD contains the metadata.

The following snippet from write_ome_tiff writes the Tiff file:

    with TiffWriter(ome_tiff_dir / self.metadata.with_suffix(".tiff").name, kind="generic") as tif:
        for index, frame in enumerate(self.get_acquisition_images()):
            if index == 0:
                metadata_str = self.modify_metadata(frame)
                tif.write(frame, contiguous=True, description=metadata_str.encode())
            else:
                tif.write(frame, contiguous=True)

While the TiffWriter class has native support for OME metadata, we do not use it in this example. Hence, the kind parameter of TiffWriter is generic not ome. The TiffWriter OmeXml class is not comprehensive and does not support the full model. We instead use the ome-types library to parse the metadata file, perform operations on it and convert to a string that is written to the OME-TIFF file using TiffWriter.

In the tif.write function, the metadata is passed to the description parameter for the first image or IFD. The contiguous argument ensures that each image is written in the same series of the tiff file.

Use of Custom Annotations

Zaber Launcher allows configurations of illuminators that are not supported by the OME-XML model. Zaber Launcher gets around this by putting the illuminator configuration in Structured Annotations that allow additional information to be added to the OME metadata.

The OME Channel assumes that each captured image plane will have a single wavelength light source which is likely in most cases. However, Zaber Microscopes additionally allow multi wavelength configurations by allowing multiple illuminators to be simultaneously on.

The current illuminator configuration is captured in structured annotations like so:

  <StructuredAnnotations>
    <MapAnnotation ID="Annotation:IlluminatorConfig:0" Namespace="Zaber">
      <Value>
        <M K="name">473A Green</M>
        <M K="hardwareChannelIndex">2</M>
        <M K="wavelengthNm">473</M>
        <M K="attenuationFraction">1</M>
      </Value>
    </MapAnnotation>
  </StructuredAnnotations>

Each different configuration has a corresponding annotation generated which is referenced under the OME Channel metadata tag for image planes. When single illuminator setups are used, the corresponding OME Channel metadata is filled in addition to the generated structured annotations.

While most third party readers will not be able to parse this information directly, it will be viewable under the OME metadata and can be parsed programmatically.
