A finer pitch lead screw will give higher resolution and increase thrust at the expense of lower maximum speed. For most applications a medium resolution (B pitch) is appropriate. For higher top speeds select a coarse resolution (D pitch) and for heavy loads or to prevent backdriving without power, select a fine resolution (A pitch).

For a complete table of specifications impacted by lead screw pitch, see the LSQ Part Specifications Comparison.

A finer pitch lead screw will give higher resolution and increase thrust at the expense of lower maximum speed. For most vertical applications a fine resolution (A pitch) is appropriate. The A pitch is non-backdriving, so it can hold its position even without power. For higher top speeds select a coarser resolution (B or D pitch).

For a complete table of specifications impacted by lead screw pitch, see the LSQ Part Specifications Comparison.
